Gomachv's 4wd RC10 project- finished!

Post by **tiger1** » Wed Nov 27, 2013 6:14 am

I am ALL EXCITED seeing this project!!

Post by **jwscab** » Wed Nov 27, 2013 11:23 am

This is the idea I have been kicking around. I was going to use pulleys off the idlers on the left side just like the MIP kit. Could leave or trim off the top shaft part of the trans. I was going to find 48 pitch pinions trimmed and drilled out to 3/16" Id for some longer shafts to allow room externally for mounting a pulley. I was going to use traxxas 4tec 15 tooth pulleys cause they are cheap.

Post by **soniccj5** » Wed Nov 27, 2013 12:01 pm

Great work here. Dual motors for a 10T would be cool!

As far as belt driven I could see cutting the top shaft section of the stealth off to save room and possibly still fit a protech body.

Looks forward to more project pictures.

Post by **teman** » Wed Nov 27, 2013 12:22 pm

Keep going, this is cool

Oh and I named it for ya

: TADA.jpg (37.88 KiB) Viewed 769 times

: TADA.jpg (37.88 KiB) Viewed 769 times

Post by **Coelacanth** » Fri Nov 29, 2013 12:05 pm

I like where you're taking this, Jeff. If 4WD RC10 conversions are so stupid-expensive and not even executed particularly well, fabricate your own.

The RC10 name is terribly ambiguous and doesn't lend itself well to nicknames or plays-on-words, but I like teman's suggestion.

Post by **GoMachV** » Fri Nov 29, 2013 5:57 pm

Nose brace tubes on (that's why the tower was left "wide" just handnt cut the tubes yet)
Cut a rear tower to allow the belt to pass, and cut the bulkhead. Installed rubber bands to test the path of the belt.
Still searching for proper pullies, I know what I WANT to do, but it would require someone to machine a custom set of pullies for me

oh Jaaaaaaaaake......

Post by **Phin** » Fri Nov 29, 2013 6:30 pm

Is the plan to mount a buggy body? Belt looks like it may a bit high for one?

Post by **GoMachV** » Fri Nov 29, 2013 6:37 pm

Haven't crossed that bridge yet but it will be close. Just paint the body one color and the racing stripe adds itself

Post by **Phin** » Fri Nov 29, 2013 6:50 pm

Lol that'll work.

BTW I really like the cut of that rear tower.

Post by **GoMachV** » Fri Nov 29, 2013 6:53 pm

It looks rougher in person

once the belt passes thru I will be able to make it more "finished"

Post by **marlo** » Fri Nov 29, 2013 7:23 pm

Very cool Jeff.

Post by **Diamond Dave** » Sat Nov 30, 2013 2:37 am

marlo wrote:Very cool Jeff.

Understatement for sure, nice work man! This is one cool build. I need to find me an anodizing guy, and get some builds going.

Post by **kink** » Sat Nov 30, 2013 4:17 am

You clever muther funker

Post by **Charlie don't surf** » Sat Nov 30, 2013 9:17 am

Wow, what have I been missing!!

Post by **SFC K** » Sat Nov 30, 2013 9:28 am

kink wrote:You clever muther funker

My thoughts exactly! Great work and can't wait to see the first racing stripe!
