Re: (2) RC10GT's - Black Pan and Plastics - #7065

Post by klavy69 »

IF you are wanting to open pandora's box you could redo your recoil. Picture the gag of the spring 'worm' out of the can of pringles type thing if you wanna have some fun with the voices in your head that told you not to mess with it. :lol: More than likely its just a weak spring or the spring picked up and let a notch or two come loose. You take the handle off the string and wind it a few times, feed it back through the pullstart hole, retie it to the handle and it will be good to go. Its good to have at least 4 hands while doing this :? . I did more than my fair share at the LHS to the point where when mine took a dump I just bought my first bumpstarter :P .

depending which battery post puller you get it might still scratch up your flywheel or if its like the ones in the picture the stamped metal prongs might spread or bend. I know I'm kinda old school but I used to get the stuck flywheels off with a vise. I use the vise as a support for the flywheel (not clamping it but just suspended between the jaws) and use a block of hardwood as a softener to hold on the crankshaft and give it a rap with a small hammer. Usually didn't have to get that extreme but it worked.

Todd
Peace and professionlism.....Kabunga signing off!!!

User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Pan and Plastics - #7065

Post by GreenBar0n »

klavy69 wrote: Mon Dec 11, 2023 11:56 pm IF you are wanting to open pandora's box you could redo your recoil. Picture the gag of the spring 'worm' out of the can of pringles type thing if you wanna have some fun with the voices in your head that told you not to mess with it. :lol: More than likely its just a weak spring or the spring picked up and let a notch or two come loose. You take the handle off the string and wind it a few times, feed it back through the pullstart hole, retie it to the handle and it will be good to go. Its good to have at least 4 hands while doing this :? . I did more than my fair share at the LHS to the point where when mine took a dump I just bought my first bumpstarter :P .

depending which battery post puller you get it might still scratch up your flywheel or if its like the ones in the picture the stamped metal prongs might spread or bend. I know I'm kinda old school but I used to get the stuck flywheels off with a vise. I use the vise as a support for the flywheel (not clamping it but just suspended between the jaws) and use a block of hardwood as a softener to hold on the crankshaft and give it a rap with a small hammer. Usually didn't have to get that extreme but it worked.

Todd
Thanks @klavy69!

The rope inside that recoil looks really badly stretched near the handle. I can't understand how it got so bad, with such little use. And after I had cleaned a bunch of screws in the ultrasonic cleaner, and then rinsed them off in the sink, the garbage disposal ate one of the (4) recoil screws - out of all the screws/bolts, it had to be one of those, I have a replacement for everything else. I'll go ahead and get the new recoil, but without the one way bearing which doubles the cost, it comes with fresh screws and a new rope, and I can feel my old bearing is still good. What's another $35 at this point :D.

I have some neoprene with adhesive back, to put in the puller jaws, to keep that soft aluminum flywheel from scratching. OS makes a puller tool for $40, that Hudy sells for $10:


User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by GreenBar0n »

Took a look to make sure the one way bearing was still good in the #2 CV engine recoil, turns out the bearing is glued in, strongly.

The CZ version on the right, is one model older, has had many more hours and pulls on it, and works like new still; the bearing is not glued in.


Trying to put that spring back in the lousy recoil unit was more trouble than it's worth, so I wadded up and threw the full amount at a new recoil unit that has the modular one way bearing, not glued in, I really believe that's part of the problem.


I'll keep the old recoil parts, just in case.

Hoping to have a full Tx/Rx set for both GT's tomorrow.

User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by GreenBar0n »

Got the flywheel puller today.

With a 'crack' it pulled off in less time than it took to setup this pic.

GT #1 engine ready to go, this one has what I think is the MIP clutch in it.

Need to find another air filter/carb rubber boot like above, for #2.

User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by GreenBar0n »

#2's body arrived today, by way of J Concepts, then a brief stop over at Andy's.



Stock box art decals, or no decals? Rear wing, or no rear wing? What would you do? (Strictly for display purposes)

User avatar
romulus22
Super Member
Posts: 2497
Joined: Wed May 19, 2010 11:30 pm
Location: KY
Has thanked: 725 times
Been thanked: 688 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by romulus22 »

Hard to go wrong with box art decal look. At least you know what it’ll look like. Definitely needs the spoiler though.

User avatar
RC10th
Approved Member
Posts: 4315
Joined: Sat Feb 16, 2013 2:51 pm
Location: Australia
Has thanked: 41 times
Been thanked: 1047 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by RC10th »

+1 for box art decals and spoiler
I was old school - when old school wasn't cool !

User avatar
Dangeruss
Approved Member
Posts: 638
Joined: Wed Jul 12, 2023 4:47 pm
Location: L.A.--->me<---N.Y.C.
Has thanked: 169 times
Been thanked: 617 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by Dangeruss »

Box Art?? Nooo.....

Green Baron.jpg

Go full Baron on it! :mrgreen:

User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by GreenBar0n »

Dangeruss wrote: Thu Dec 14, 2023 2:26 am Box Art?? Nooo.....


Green Baron.jpg


Go full Baron on it! :mrgreen:
:lol: That would be epic! Can you imagine the disgust and retribution that would bring me, defacing Andy's work like that.


The box art decal votes have it. This won't be an easy feat though to get all of those decals, specifically the ASC7197 sheet, to make matters worse there are (2) versions of the 7197 sheet, the GT2 (blue pan version) also calls it 7197 and it's completely different.

There were at least (3) decal sheets in the GT box, 7197, 6196 (?), and 3811. The front RC10gt sticker across the hood I can't find on any sheet.

3811

User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by GreenBar0n »

#2's engine problems:
Carb rotary slide is frozen in one spot, soaking it in 99% alcohol, will give it the heat gun treatment, after a few hours in the sauce.

I need to get a longer head bolt, to reach down further in to the OS .12 case, past the stripped thread section, and grab the remaining threads below, there are plenty, at least another 5-8mm.

The problem I'm having is the dimensions, is this an M2, or an M3 bolt? I measured the diameter of the current head-bolt shaft with some cheapy HF calipers:

When I look at a chart, the shaft diameter measurement would seem to be an M3 according to this:

Can anyone figure out what I need?

The current shaft length of the head bolt is 12mm, between 17-20mm would be the ideal length, but need to figure out diameter and thread pitch still.

User avatar
RC10th
Approved Member
Posts: 4315
Joined: Sat Feb 16, 2013 2:51 pm
Location: Australia
Has thanked: 41 times
Been thanked: 1047 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by RC10th »

I think they are 2.5mm from memory, or 2.8mm.... They are a weird size....

:lol: @ the green baron themed GT
I was old school - when old school wasn't cool !

User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by GreenBar0n »

RC10th wrote: Thu Dec 14, 2023 5:31 am I think they are 2.5mm from memory, or 2.8mm.... They are a weird size....

:lol: @ the green baron themed GT
I'll just order a bolt kit with M2 and M3, and hope to get it right.

User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by GreenBar0n »

Found a place that appears to sell reproductions of all of the box art RC10gt decals. Anyone have any experience with this shop?
https://mciracing.ca/products/1-10th-associated-rc10-gt-box-art-decals


That sure looks like all of them.

Just noticed that the box art decals cover the 10 in RC10, with GT. They must've had to cut up the GT decals because they were too wide for the wing and doors.

They took Paypal, $23.73 for the sheet above. We'll see how this turns out. Very little risk to reward here.

User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by GreenBar0n »



I never watched this tape, all of these years, I winged mine out of the box, AKA the 'hard way'. I missed so much vital info, so glad to be able to watch this now.

User avatar
GreenBar0n
Super Member
Posts: 835
Joined: Sun Nov 05, 2023 11:08 pm
Has thanked: 636 times
Been thanked: 295 times

Re: (2) RC10GT's - Black Tub and Plastics - #7065

Post by GreenBar0n »

Found the correct specs on the OS Max .12 CV head bolts, M2.6x12 is what it came with.
https://www.manualslib.com/manual/645611/O-S-Engine-Max-12cv-Series.html?page=21#manual

I found M2.6x16mm at the longest. Really wanted 20mm, so I could cut it to be as long as possible.
https://www.mcmaster.com/products/socket-head-cap-screws/thread-size~m2-6/length~16-mm/

Found some M2.5x20 with 0.45mm thread pitch, shorter head cap, but these should work.
