onyx 14 turn motor with Novak T-4 Drawing to much power?
i am having an issue with this setup. It is causing some radio interference and i am thinking it is mostly because if the high amperage draw of this motor? if i ease into the throttle and gently go up to full speed it works pretty flawless. If i get into the the throttle very quickly it cuts out the controls all together. Can someone help me out with this. I was using a vintage airtronics controller and that really went nuts. I upgraded to a modern 2.4 GHZ controller and it is now doing this. I am guessing if i ad a capacitor to the ESC that i can fix this problem (based on my research any way). But can someone explain to me what size cap to use and if this will solve my problem? The T-4 manual states that it has not motor turn limit so it should not be related to the ESC other than the AMP draw from the motor.
Thanks for your help!
Thanks for your help!
- slapshot1979
- Approved Member
- Posts: 928
- Joined: Wed May 26, 2010 6:18 pm
- Location: GTA Ontario,Canada
Re: onyx 14 turn motor with Novak T-4 Drawing to much power?
My first thought would be battery. if you ease into it and theres no problem, but gas it and it cuts out I would say your battery cant supply the amps the rest of the system wants.
Sleeps with a night light on, not because he's scared of the dark but because the dark is scared of him...........stay thirsty my friends
Re: onyx 14 turn motor with Novak T-4 Drawing to much power?
Could it also be the CF chassis causing the interference?
-
- Approved Member
- Posts: 384
- Joined: Wed Mar 07, 2012 12:55 am
- Location: Moravia NY 13118 USA
- Been thanked: 5 times
Re: onyx 14 turn motor with Novak T-4 Drawing to much power?
this cheap battery has some whimpy wires i noticed. could be some of the issue.
- slapshot1979
- Approved Member
- Posts: 928
- Joined: Wed May 26, 2010 6:18 pm
- Location: GTA Ontario,Canada
Re: onyx 14 turn motor with Novak T-4 Drawing to much power?
Spectrum sells a capacitor they call it a stutter stopper $5. If you feel this will help. I run them on everything.
Sleeps with a night light on, not because he's scared of the dark but because the dark is scared of him...........stay thirsty my friends
-
- Approved Member
- Posts: 384
- Joined: Wed Mar 07, 2012 12:55 am
- Location: Moravia NY 13118 USA
- Been thanked: 5 times
Re: onyx 14 turn motor with Novak T-4 Drawing to much power?
something like this maybe?
I was thinking of installing one directly wired into the ESC like some of the more modern Novak's have pre installed.
http://www.google.com/products/catalog?q=capacitor+novak&hl=en&client=firefox-a&rls=org.mozilla:en-US:official&prmd=imvns&bav=on.2,or.r_gc.r_pw.r_cp.r_qf.,cf.osb&biw=1600&bih=809&um=1&ie=UTF-8&tbm=shop&cid=7988458844438393399&sa=X&ei=aCOYT4PUL6v06AHKoKXCBg&ved=0CHAQ8wIwAQ
I was thinking of installing one directly wired into the ESC like some of the more modern Novak's have pre installed.
http://www.google.com/products/catalog?q=capacitor+novak&hl=en&client=firefox-a&rls=org.mozilla:en-US:official&prmd=imvns&bav=on.2,or.r_gc.r_pw.r_cp.r_qf.,cf.osb&biw=1600&bih=809&um=1&ie=UTF-8&tbm=shop&cid=7988458844438393399&sa=X&ei=aCOYT4PUL6v06AHKoKXCBg&ved=0CHAQ8wIwAQ
- jwscab
- Super Member
- Posts: 6495
- Joined: Wed Jan 28, 2009 9:42 am
- Location: Chalfont, PA
- Has thanked: 10 times
- Been thanked: 447 times
Re: onyx 14 turn motor with Novak T-4 Drawing to much power?
yes a stutter stopper/surge cap can definitely help. What happens is the voltage drops momentarily as you effectively 'short' the battery. If the cells can't supply enough current, or the wires have too much resistance, the voltage drops so far that the regulator no longer regulates and the receiver effectively loses power and you lose radio control. Having the capacitor on the receiver acts as a backup 'battery' to supply current for that split second.
You want to install the cap in the 'batt' connection of the reciever, so it supplies power to the receiver.
You want to install the cap in the 'batt' connection of the reciever, so it supplies power to the receiver.
-
- Approved Member
- Posts: 384
- Joined: Wed Mar 07, 2012 12:55 am
- Location: Moravia NY 13118 USA
- Been thanked: 5 times
Re: onyx 14 turn motor with Novak T-4 Drawing to much power?
i just made a stutter stopper/glitch buster with a 1000uF 35V capacitor and an old servo lead. I hope the Capacitor is large enough though.
- Goatless
- Approved Member
- Posts: 508
- Joined: Mon Jan 30, 2012 8:25 pm
- Location: Memphis, TN
- Been thanked: 2 times
Re: onyx 14 turn motor with Novak T-4 Drawing to much power?
Here is one from Team Associated.
http://www.amainhobbies.com/product_info.php/cPath/1_221_1364/products_id/148201/n/LRP-BEC-Stabilizing-Capacitor
I use a Spektrum BEC in my truck. I just "jazzed" it up a little.
http://www.amainhobbies.com/product_info.php/cPath/1_221_1364/products_id/148201/n/LRP-BEC-Stabilizing-Capacitor
I use a Spektrum BEC in my truck. I just "jazzed" it up a little.
