back in the day i "cut my teeth" racing dirt oval.
started with a jrx2 based edm, ended with wedge bodied cobbed together rc10/houge kit w/jg lowering kit.
we also had a bbt or ascot sprinter. i gotta get pics up of that so you guys can tell me what i have (my dad bought it used, guy said is was bbt)
anyway, i'm jonesing for dirt oval action. the track that the vonats is being held at has a nice oval track, so that got me thinking again.
i'd like to discuss oval conversions for the rc10, variations, setups, what some of you have found to be good or bad.
my last oval race was sometime in 1991, so it's been a while.
so far i've gather a few bits:
macallister lowering kit (not dead set on it, just bought one of a member a while back "just in case" lol)
a rc10ce to use as a base for a edm or latemodel/wedge
dad's old sprinter (found that bad boy on a shelf at rchr, the old vonats track) it needs a restore. mip gearbox on that one, also needs restore.
so what's the good word out there about dirt oval?
old is new edm?
started with a jrx2 based edm, ended with wedge bodied cobbed together rc10/houge kit w/jg lowering kit.
we also had a bbt or ascot sprinter. i gotta get pics up of that so you guys can tell me what i have (my dad bought it used, guy said is was bbt)
anyway, i'm jonesing for dirt oval action. the track that the vonats is being held at has a nice oval track, so that got me thinking again.
i'd like to discuss oval conversions for the rc10, variations, setups, what some of you have found to be good or bad.
my last oval race was sometime in 1991, so it's been a while.
so far i've gather a few bits:
macallister lowering kit (not dead set on it, just bought one of a member a while back "just in case" lol)
a rc10ce to use as a base for a edm or latemodel/wedge
dad's old sprinter (found that bad boy on a shelf at rchr, the old vonats track) it needs a restore. mip gearbox on that one, also needs restore.
so what's the good word out there about dirt oval?
old is new edm?
-
- Approved Member
- Posts: 1167
- Joined: Fri Mar 11, 2011 4:20 pm
- Location: Houston
- Been thanked: 4 times
Re: dirt oval discussion
I've got a JCar direct drive which was brilliant on ovals. Mine is for the JRX2. I thought the 5 link rear suspension was wonderful even for oval. The direct drive puts the motor off to the left so it helped out with weight distribution.
Raborn Racing Originals Shapeways store
-
- Approved Member
- Posts: 8921
- Joined: Tue Apr 08, 2008 2:44 pm
- Location: USA
- Been thanked: 8 times
Re: dirt oval discussion
If Eddie (transamman) still has that Terminator 2.25 in the B/S/T avail (super cheap) jump on it, the r&d (later Kranzels) RC10 Terminator was and is still a super capable
(USOWC winning chassis at least 25 times).
A stock CE with a cut rear tower and .71's in the rear and a 0/0 or 0/1.5 rear toe setup and a Bomber shell or EDM is a blast, and while we ran Graphite cars BITD the tub car isn't bad
I trued and grooved some foams for Bscotti a couple of years ago for his Customworks Dominator he wanted to bring, so I'm sure there are others that will follow suit!
(USOWC winning chassis at least 25 times).
A stock CE with a cut rear tower and .71's in the rear and a 0/0 or 0/1.5 rear toe setup and a Bomber shell or EDM is a blast, and while we ran Graphite cars BITD the tub car isn't bad
I trued and grooved some foams for Bscotti a couple of years ago for his Customworks Dominator he wanted to bring, so I'm sure there are others that will follow suit!
- PBR Allstar
- Approved Member
- Posts: 805
- Joined: Mon Apr 30, 2007 10:30 pm
- Location: Sonoma, Ca
- Has thanked: 1 time
- Been thanked: 3 times
Re: dirt oval discussion
Dirt oval is my primary form of racing, I run mod sprint, 13.5 sprint, nitro sprint, and 10.5 edm on a pretty regular basis. I fill the gaps with paved oval 17.5 pan car and 13.5 non wing sprint car.
here's an example of a WOIN style 2.25 terminator with some rare period parts that I built. It went to another member here on the board.
here's an example of a WOIN style 2.25 terminator with some rare period parts that I built. It went to another member here on the board.
- uniquenamehere
- Approved Member
- Posts: 553
- Joined: Tue Jun 07, 2011 6:34 am
- Location: Ontario, Canada
- Been thanked: 2 times
- scr8p
- Administrator
- Posts: 16540
- Joined: Tue Feb 07, 2006 9:46 pm
- Location: Northampton, PA
- Has thanked: 28 times
- Been thanked: 975 times
-
- Approved Member
- Posts: 8921
- Joined: Tue Apr 08, 2008 2:44 pm
- Location: USA
- Been thanked: 8 times
Re: dirt oval discussion
that's a nice carPBR Allstar wrote:Dirt oval is my primary form of racing, I run mod sprint, 13.5 sprint, nitro sprint, and 10.5 edm on a pretty regular basis. I fill the gaps with paved oval 17.5 pan car and 13.5 non wing sprint car.
here's an example of a WOIN style 2.25 terminator with some rare period parts that I built. It went to another member here on the board.
Re: dirt oval discussion
dagnabbit, i definetley didn't intend on buying another car.....
but i just pm'd transamman about that terminator.
looks like i'll be shopping at kipps when the time comes. lol
still wanna get an edm going on the ce, most likey try to find a graphite chassis for it.
what's the word on the macallister vs jg lowering kits?
but i just pm'd transamman about that terminator.
looks like i'll be shopping at kipps when the time comes. lol
still wanna get an edm going on the ce, most likey try to find a graphite chassis for it.
what's the word on the macallister vs jg lowering kits?
- scr8p
- Administrator
- Posts: 16540
- Joined: Tue Feb 07, 2006 9:46 pm
- Location: Northampton, PA
- Has thanked: 28 times
- Been thanked: 975 times
Re: dirt oval discussion
to be perfectly honest, with all of the "dirt oval hop-ups" there was back then, at the end of the day, almost nothing beat a well prepped, basically stock rc10 (at the tracks i raced). offset chassis' worked though.
Re: dirt oval discussion
i would agree, until custom works released the intimidators.
at least at my track (indoor, blue groove, banked oval) we couldn't compete against that car.
the terminator is just cool, and it's a good price.
i would like to find or make and offset chassis at some point for a rc10 based car.
at least at my track (indoor, blue groove, banked oval) we couldn't compete against that car.
the terminator is just cool, and it's a good price.
i would like to find or make and offset chassis at some point for a rc10 based car.
- PBR Allstar
- Approved Member
- Posts: 805
- Joined: Mon Apr 30, 2007 10:30 pm
- Location: Sonoma, Ca
- Has thanked: 1 time
- Been thanked: 3 times
Re: dirt oval discussion
I always ran a stock front CE tower and a cut down rear tower so I could run .71 shocks. From there it's just rubbing on setup. I have a good thread on here somewhere with lots of pics of my rc10 based edm's
- PBR Allstar
- Approved Member
- Posts: 805
- Joined: Mon Apr 30, 2007 10:30 pm
- Location: Sonoma, Ca
- Has thanked: 1 time
- Been thanked: 3 times
Re: dirt oval discussion
Most of the parts on that care are from Kranzel's. You can still buy almost all the parts as well.uniquenamehere wrote:That's a lot of billet! Did you make those or buy? nice
-
- Approved Member
- Posts: 1167
- Joined: Fri Mar 11, 2011 4:20 pm
- Location: Houston
- Been thanked: 4 times
Re: dirt oval discussion
There used to be a unique old pan car from either Bolink or Parma that was basically the solid rear axle setup from typical pan cars but was split down the middle so that each half was now essentially a swing axle with the motor on the right side of it. It had 2 rear shocks. Weird setup. Barry Raborn ran a custom dirt oval car that used this rear end with an RC10 front end in a dirt oval Nats event. He was the only person in the A-main that was not running the Custom Works car. He led the A-main until about the last 30 seconds when his batteries fell off. He's still got most of that car. I need to get some pics of it.
Raborn Racing Originals Shapeways store
Re: dirt oval discussion
it's official, i now own a terminator.
now i just gotta wait for some extra funds to buy parts for all three lto's.
now i just gotta wait for some extra funds to buy parts for all three lto's.
