RC10T Bulkhead
RC10T Bulkhead
I know that the front bulkheads are the same, but will the GT rear bulkhead work for the RC10T?
- jwscab
- Super Member
- Posts: 6506
- Joined: Wed Jan 28, 2009 9:42 am
- Location: Chalfont, PA
- Has thanked: 10 times
- Been thanked: 453 times
Re: RC10T Bulkhead
it's not the same, but I do believe it will physically bolt to the chassis where the bulkhead goes. since its for a gas car, it has no battery cup built in, and would need either the GT shock tower, or your own custom one.
Re: RC10T Bulkhead
Can you use the battery two cup method that I have seen people use for the Rc10T's? Will the rear suspension mount for the GT also fit the RC10T?
-
- Approved Member
- Posts: 2022
- Joined: Sat Jan 20, 2007 4:41 pm
- Location: Cape Carteret.NC
- Been thanked: 22 times
- JK Racing
- Super Member
- Posts: 4603
- Joined: Thu Jul 19, 2007 2:32 pm
- Location: Placentia, CA
- Has thanked: 103 times
- Been thanked: 200 times
Re: RC10T Bulkhead
I think the rear arm mounts will not have the correct anti squat or toe in to run on the electric trucks/buggies.
I have a set I should test, bolt them onto the electric mounts and put a hinge pin into each mount to see if the angles match.
I have a set I should test, bolt them onto the electric mounts and put a hinge pin into each mount to see if the angles match.
--Joey --
Vintage A&L and Factory Works
Old School Racer & Vintage RC Car nut
JKRacingRC.com
Vintage A&L and Factory Works
Old School Racer & Vintage RC Car nut
JKRacingRC.com
-
- Approved Member
- Posts: 748
- Joined: Wed Aug 26, 2009 3:43 pm
- Location: Syracuse, NY
- Has thanked: 1 time
- Been thanked: 2 times
Re: RC10T Bulkhead
That's correct; not sure about the toe-in, but the GT rear arm mounts don't have any anti-squat molded in. You can use a washer under the mount at the front screw. The holes are very close, if not exact, but you'll need to enlarge the holes a little for an 8-32 screw.
Re: RC10T Bulkhead
SteveK wrote:That's correct; not sure about the toe-in, but the GT rear arm mounts don't have any anti-squat molded in. You can use a washer under the mount at the front screw. The holes are very close, if not exact, but you'll need to enlarge the holes a little for an 8-32 screw.
What are you meanwhen you say anti squat? Are talking the concave area of the originals?
-
- Approved Member
- Posts: 748
- Joined: Wed Aug 26, 2009 3:43 pm
- Location: Syracuse, NY
- Has thanked: 1 time
- Been thanked: 2 times
Re: RC10T Bulkhead
Anti-squat is what keeps the rear of the car from squatting down under acceleration. If you look at the truck from the side, the rear suspension arms are about tilted up about 3 degrees (like the front is kicked up at 30 degrees). This angle makes it a little harder to compress the suspension when pushing straight down, like the weight transfer from the motor. It can also affect the handling of the truck over bumps and in corners, but weight transfer to the rear is the biggest reason for it.
The RC10GT has very different weight distribution than the RC10T. On the GT, everything except the receiver battery is ahead of the rear wheels, while the 10T has the motor (15% of the truck's total weight) behind the rear axles. Because of this, the GT worked better without any anti-squat built in.
The RC10GT has very different weight distribution than the RC10T. On the GT, everything except the receiver battery is ahead of the rear wheels, while the 10T has the motor (15% of the truck's total weight) behind the rear axles. Because of this, the GT worked better without any anti-squat built in.
-
- Approved Member
- Posts: 748
- Joined: Wed Aug 26, 2009 3:43 pm
- Location: Syracuse, NY
- Has thanked: 1 time
- Been thanked: 2 times
Re: RC10T Bulkhead
These were the best pictures I could find, everything else was for 4-link suspensions (drag racers play with this a lot, to help get better traction off the line).
![Image](http://www.rc411.com/howtos/168/06.jpg)
![Image](http://www.rc411.com/howtos/168/07.jpg)
http://www.rc411.com/pages/howto.php?howto=62&page=1
![Image](http://www.rc411.com/howtos/168/06.jpg)
![Image](http://www.rc411.com/howtos/168/07.jpg)
http://www.rc411.com/pages/howto.php?howto=62&page=1
-
- Approved Member
- Posts: 748
- Joined: Wed Aug 26, 2009 3:43 pm
- Location: Syracuse, NY
- Has thanked: 1 time
- Been thanked: 2 times
Re: RC10T Bulkhead
Definitely the anti-squat, and possibly the toe-in as well. I believe the rear arm mounts came with 0, 1-1/2, and 3 degrees of toe-in, but anti-squat was the same on all of them.
Re: RC10T Bulkhead
SteveK wrote:Definitely the anti-squat, and possibly the toe-in as well. I believe the rear arm mounts came with 0, 1-1/2, and 3 degrees of toe-in, but anti-squat was the same on all of them.
Thanks for the information. I will have to buy them to find out. lol It's only money, what the hell.
-
- Approved Member
- Posts: 748
- Joined: Wed Aug 26, 2009 3:43 pm
- Location: Syracuse, NY
- Has thanked: 1 time
- Been thanked: 2 times
Re: RC10T Bulkhead
Those are GT mounts, correct? If so then they won't have anti-squat. Somebody makes some gold aluminum mounts for the electric cars, I'm sure somebody on here has the link.
You should be able to tell if the mount has anti-squat from looking at it. The 'barrel' the pin slides through will slant downward towards the rear, so it will actually be above the the flat part of the mount in front and hang below the chassis in the rear.
You should be able to tell if the mount has anti-squat from looking at it. The 'barrel' the pin slides through will slant downward towards the rear, so it will actually be above the the flat part of the mount in front and hang below the chassis in the rear.
