Transmission Internal Drive Ratios

Post by Eau Rouge »

Lots of people are running their vintage cars more and more, and using contemporary electronics in them on the track. Gearing is always an issue for many newbies and vets, alike. To get a proper gear ratio for your motor, battery, tire and chassis, it's important to know the final drive ratio of the transmission or gearbox in your buggy. Here's a list I have been compiling for a while of various final internal ratios of different buggies. I know I am missing some, so if you know of any that aren't on the list—old or new—feel free to post them and I'll update the master list in this first post.

Transmission Internal Drive Ratios
  • 1.86:1 -- Team Pit Stop Chain Drive
    1.87:1 -- Team Associated 6-gear RC10
    1.87:1 -- Team Pit Stop Chain Drive
    2.00:1 -- Team Pit Stop Chain Drive (optional)
    2.14:1 -- Team Pit Stop Chain Drive (optional)
    2.28:1 -- Team Pit Stop Chain Drive (optional)
    1.96:1 -- RPM Stealth Buggy Conversion (light gray case)
    2.00:1 -- MIP "Stealth"
    2.10:1 -- Team Losi XXX4
    2.18:1 -- Team Losi JRX2 - JRXT
    2.19:1 -- Team Losi XX Buggy
    2.20:1 -- Yokomo MR4-BX
    2.22:1 -- A&L Lethal Weapon
    2.25:1 -- Team Associated Stealth RC10 - RC10T - Dual Sport
    2.29:1 -- AYK Pro Radiant
    2.33:1 -- Yokomo YZ10 - 870C
    2.40:1 -- Team Associated B2
    2.40:1 -- Team Associated B3 - T3
    2.43:1 -- Team Losi XXX CR
    2.43:1 -- Schumacher CAT - XL - Top Cat
    2.56:1 -- Team Losi XXX BK2 MF2
    2.60:1 -- Kyosho RB5
    2.60:1 -- Team Associated T2 - GT
    2.60:1 -- Team Associated B4 - T4 - SC
    2.60:1 -- Team Losi XX Truck
    2.61:1 -- Team Losi XXT CR
    2.61:1 -- RPM Stealth Truck Conversion (white case)
    2.67:1 -- Duratrax Evader SX - BX
    2.72:1 -- Schumacher 98/99/Axis
    2.72:1 -- Traxxas Stampede - Rustler - Bandit
    2.90:1 -- TAG Coyote
    3.03:1 -- Kyosho Ultima


(Spur gear teeth/pinion teeth) X transmission ratio = FDR

User avatar
Coelacanth
Approved Member
Posts: 7375
Joined: Thu Jul 29, 2010 6:20 pm
Location: Alberta, Canada
Has thanked: 16 times
Been thanked: 291 times

Re: Transmission Internal Drive Ratios

Post by Coelacanth »

Kyosho Optima? 8)
Completed projects: CYANide Onroad Optima | Zebra Gold Optima | Barney Optima | OptiMutt RWD Mid
Gallery - Coel's Stalls: Marui Galaxy & Shogun Resto-Mods | FrankenBuff AYK Buffalo | 1987 Buick GNX RC12L3

User avatar
Eau Rouge
Approved Member
Posts: 2225
Joined: Sat Jul 29, 2006 11:59 pm
Location: Aurora, Illinois
Has thanked: 2 times
Been thanked: 2 times

Re: Transmission Internal Drive Ratios

Post by Eau Rouge »

I know which ones are missing... I obviously don't know what they are. :wink: :mrgreen:

User avatar
askbob
Approved Member
Posts: 1735
Joined: Sun Apr 03, 2011 11:24 am
Location: KY
Been thanked: 3 times

Re: Transmission Internal Drive Ratios

Post by askbob »

Much appreciated!

User avatar
dinglem
Approved Member
Posts: 1381
Joined: Tue Oct 25, 2016 9:45 am
Location: Lichfield, UK
Has thanked: 244 times
Been thanked: 633 times

Re: Transmission Internal Drive Ratios

Post by dinglem »

AYK Pro Radiant - 2.29

TAG Coyote - 2.90
CAT SWB&XL, Meteor (x3), RC10 custom, RC10 Graphite, Goldpan, 870c (x2), Works 91, Samurai, Pro Radiant (x2), Mini Mustang&Maxima, Mid Turbo, TOP Hybrid , Coyote, Hot Trick Optima, Supercharge, Brimod, 'Rory Cull' Hotshot, SRB.

User avatar
Lowgear
Administrator
Posts: 3954
Joined: Tue Feb 07, 2006 1:00 pm
Location: New England
Has thanked: 78 times
Been thanked: 606 times

Re: Transmission Internal Drive Ratios

Post by Lowgear »

Thanks, I added them to the list since Eau Rouge isn't around to do it. :)

aip47-2008
Approved Member
Posts: 1186
Joined: Sun Feb 08, 2009 9:20 pm
Location: Spokane, WA
Has thanked: 135 times
Been thanked: 23 times

Re: Transmission Internal Drive Ratios

Post by aip47-2008 »

1.86:1 -- Team Pit Stop Chain Drive

User avatar
Lowgear
Administrator
Posts: 3954
Joined: Tue Feb 07, 2006 1:00 pm
Location: New England
Has thanked: 78 times
Been thanked: 606 times

Re: Transmission Internal Drive Ratios

Post by Lowgear »

Thanks, added it. :)
